305 Stainless Steel Strip, Coil & Sheet
UNS: S30500
EN-DIN: 1.4303
products & materials
AMS 5514 Stainless Steel Strip, Coil & Sheet
- AMS 5514
- ASTM A240
Our wide capabilities give us a unique ability to supply all of your 305 stainless steel strip, coil, and sheet needs.
description
305 Stainless Steel Alloy Description:
305 grade stainless has similar corrosion resistance as 304 and has good oxidation resistance in air up to 1650 F (899 C). 305 can be readily formed and deep drawn into complex shapes due to its lower strength and work hardening rate and will remain nonmagnetic after cold work unlike 301 or 304. A caution is autogenous welds in 305 are more sensitive to hot cracking than 304 or 304L. 305 stainless steel strip, coil, and sheet can be used for a variety of applications.
applications
305 Stainless Steel Alloy Uses & Applications:
Industries supplied include:
- Appliances
- Kitchen
- Utensils
- Tank covers
- Other deep drawn parts
Nominal Composition
| C | Mn | P | S | Si | Cr | Ni | N | Fe | |
|---|---|---|---|---|---|---|---|---|---|
| MIN | – | – | – | – | – | 17.0 | 10.0 | – | – |
| MAX | 0.012 | 2.0 | 0.045 | 0.030 | 1.00 | 19.0 | 13.0 | 0.10 | BAL |
Physical Properties
| At 70°F | At 20°C | |
|---|---|---|
| Density | 0.29 lb./in³ | 7.99 g/cm³ |
| Modulus of Elasticity (E) | 28.0 x 10³ ksi | 193 x 10³MPa |
| Coefficient of Expansion | 9.6 x 10⁻⁶ microinches/in.-°F (32-212°F) | 17.3 μm/m-°C (0-100°C) |
| Electrical Resistivity | 28.4 μ ohm.in | 72 μ ohm.cm |
| Thermal Conductivity | 9.4 Btu-in./ft.²hr.-°F (100°C) | 16.2 W/m-K 100°C) |
Typical Room Temperature Mechanical Properties
Typical Mechanical Properties
Typical mechanical properties are based on AK source, ASTM A240.
| Condition | Tensile Strength Min (UTS) | 0.2% YS Min | Elongation% in 2” Min (50.8 mm) | Hardness Rockwell |
|---|---|---|---|---|
| Annealed (Min) | 85 ksi (586 MPa) | 35 ksi (241 MPa) | 55% | 70 HRBW (Max) |
Limitation of Liability and Disclaimer of Warranty:
- The content in these data sheets is provided primarily by third-party melting mills and is provided for reference only. It is not intended for engineering or design.
- Applications may be discussed, however, Combined Metals Company, LLC, does not recommend or endorse any material for any particular end use or application.
- The data included in this data sheet are typical values and may vary.
- Combined Metals Company, LLC, makes no representations or warranties, express or implied, as to the accuracy, completeness, condition, suitability, performance, fitness for a particular purpose, or merchantability of any information contained in any data sheet.
In no event will Combined Metals Company, LLC, be liable for any damages whatsoever arising from the use of the information included in the data sheets.
